SC600-WP86-DIM 433.92Mhz
Technical Parameters
Dimmer
| Working temperature | -20-60℃ | Supply voltage | DC12V-24V |
| Static power consumption | <1W | Mode | 3 |
| Grayscale | 256 levels | Speed stage | 100 grade |
| External dimension | L91*W88*H24 mm | Packing size | L102*W102*H66 mm |
| Net weight | 280g | Gross weight | 300g |
| Output | 3 channel | Max. Output current | ≤8A(each channel) |
| Output power | 288W/12V; 576W/24V | RF distance | ≤20m |
| PWM frequency | 433.92Mhz | Memory function | support |
Remote control
| Working temperature | 0-45℃ | Working voltage | AC90-265V(50/60Hz) |
| Standby current | 0.2W | Working power | 2W |
| Net weight | 130g | RF frequency | 433.92MHz |
| Dimension | 86*86*34mm | RF distance | ≤20m |
| Structure | 86-type European standard | ||
